Routing — IP_Router / NVision 15 router instances • GV NVision GRD & SWP-08
R
SDI Core Router
N-VISION GRD
| Equipment | Redundancy |
|---|
| GV NV9000 — SDI Core (256×256) | Dual path (A/B) |
R
SDI Gallery Router
N-VISION GRD
| Equipment | Redundancy |
|---|
| GV NV9000 — SDI Gallery | Dual path (A/B) |
| Gallery Audio Router 1–5 | Dual path (A/B) |
R
ASI & Ancillary Routers
N-VISION / UDP GRD
| Equipment | Function |
|---|
| ASI Router | Transport stream routing |
| Prompt Router | Talkback feeds |
| Analogue Router | Mic/LTC analogue audio |
| Returns Router | Return video feeds |
R
Specialist Routers
N-VISION / SWP-08
| Equipment | Protocol | Redundancy |
|---|
| RS-422 Router | N-VISION | Single |
| LTC Router (Timecode) | N-VISION | Single |
| L-Band Router | N-VISION | Single |
| Post Production Router | N-VISION | Dual path (A/B) |
| ES Router | N-VISION | Single |
IP
IP / GV Convergent
NV9000 / SWP-08
| Equipment | Protocol | Redundancy |
|---|
| NV9000 GVC (IP Main) | NV9000 | Dual path (A/B) |
| Kahuna Vision Mixer | Kahuna TCP | Single |
| Amazon/ATER Router | SWP-08 | Dual path (A/B) |
Processing — Synapse2 / Axon2 37+ frames • Axon Synapse SNMP/HTTP
Ax
Studio & Engineering
Synapse HTTP
| Frame | Location | Cards |
|---|
| ST_FRM01 | CTA A06.04 | Studio processing |
| ST_FRM02 | CTA A07.04 | Studio processing |
| ENG_FRM01 | ENG A01.04 | Engineering workshop |
Ax
Live Gallery Frames
Synapse HTTP
| Frame | Location | Cards |
|---|
| LG_FRM01–06 | CTA G06–G08 | Frame sync, DA, embedders, keyers, Dolby |
| Frame | Location | Cards |
|---|
| MCR_FRM01–11 | CTA D17–D18 | Upconverters, DAs, Dolby encode/decode |
Ax
Amazon/ATER Frames
Synapse HTTP
| Frame | Location | Cards |
|---|
| AMZ_01–09 | ATER Rack | UHD HDR PQ, Dolby E, DA, toolbox embedders |
Comms — RiedelArtistDrv 250+ talkback panels • Riedel Artist protocol
Ri
Riedel Artist Matrix
Riedel TCP/IP
| Component | Devices | Panel Types |
|---|
| Artist Main Matrix | 9 driver instances | RCP-1012, RCP-1028, DCP-1016 |
| Monitor/PTI/Alias/Gain | Sub-drivers | CCP-1116, RCP-1112, RCP-1128 |
Ri
Panel Distribution
~250 panels
| Area | Qty | Types |
|---|
| Galleries A–D (PCRs) | ~60 | RCP-1028, DCP-1016 |
| Live Galleries 1–9 | ~80 | RCP-1012, CCP-1116 |
| MCR / TX / Presentation | ~40 | RCP-1028, RCP-1128 |
| Studios & Floors | ~30 | DCP-1016, RCP-1012 |
| Dubbing / Edit / Remote | ~40 | Mixed |
Vision Mixing — Sony / Kahuna Gallery vision mixers • Sony MVS & GV Kahuna
Mx
Gallery Mixers (Sony)
Sony/GV Protocol
| Mixer | Gallery | Type |
|---|
| Gallery A–D Mixers | PCR A–D | Sony vision mixer |
| Gallery 1–9 Mixers | LG 1–9 | Sony vision mixer |
| IP Gallery (Kahuna) | IP Gall | Kahuna vision mixer |
Audio Mixing — Lawo / Dante Lawo RVON matrix + Audinate Dante network
Lw
Lawo Audio Matrix
Lawo RVON
| Equipment | Redundancy | Function |
|---|
| Lawo mc²56 Core | Dual path (A/B) | Main audio matrix routing |
Da
Dante Audio Network
Dante API (HTTPS)
| Equipment | Channels | Function |
|---|
| Dante Domain Manager | — | Network audio management |
| Source Channels | 8000 src | Audio source routing |
| Dest Channels | 8000 dst | Audio destination routing |
Displays — Multi_Kaleido & Prismon 20+ MV heads + UMD engines
MV
Miranda Kaleido (SDI)
Miranda KX API
| Multiviewer | Inputs | Area |
|---|
| MCR KX | 128-input | Master Control |
| TX MV 1–5 | 32 each | Transmission |
| PCR A–D MVs | 16 each | Galleries |
| IPTV & TX1 MVs | 32 | IPTV/Encoding |
Pr
Prismon Multiviewers (IP)
Prismon HTTP
| Multiviewer | Quantity | Area |
|---|
| IP Gallery MVs | 2 heads | IP Gallery |
| Prismon cluster 1 | 18 heads | Various |
| Prismon cluster 2 | 29 heads | Extended IP |
U
UMD / TSL Displays
TSL v5 / SNMP
| Equipment | Quantity | Function |
|---|
| TSL MDU | 1 controller | Under-monitor displays |
| UMD Engines | 35 instances | Tally/label output |
Monitoring — ttsnmp & BNCS_NMS 60+ satellite receivers & codecs • SNMP
IRD
Satellite Receivers
SNMP (ttsnmp)
| Equipment | Quantity | Monitoring |
|---|
| Ericsson RX8200 | 19 receivers | Freq, BER, Eb/N0, Lock |
| Additional Satellite RX | 40+ receivers | Signal quality, decode status |
NMS
ISDN Codecs
SNMP (BNCS_NMS)
| Codec | Quantity | Type |
|---|
| ISDN Audio Codecs | 23 units | ISDN audio codec |
| Glensound GSGC6 | Multiple | Commentary codec |
Cameras & Recording Visca32 PTZ + Blackmagic HyperDeck
PTZ
PTZ Cameras (VISCA)
VISCA Serial
| Camera | Location | Control |
|---|
| Studio A–D PTZ | Studios | Pan/Tilt/Zoom/Focus/Iris |
| VAR PTZ Camera | VAR Room | Pan/Tilt/Zoom/Focus/Iris |
HD
Blackmagic HyperDeck
HyperDeck TCP
| Deck | Location | Function |
|---|
| MCR Deck 4B | PLMC | Record/Playback |
Miscellaneous Dish positioners + GPI triggering
Ds
Dish Positioners (Rescon)
Serial RS-485
| Equipment | Size | Band |
|---|
| Dish Positioner 1 | 3.7 metre | C/Ku band |
| Dish Positioner 2 | 5.6 metre | C band |
GP
GPI Interface
GPIO / Serial
| Equipment | Function |
|---|
| GPI 4 Routes | Router trigger on contact closure |
| Mixer GPI Input PTI | On-air tally to GPI bus |
| Miranda Panel Floor GPIO | Cue lights, standby |
